產品運用-安防系統
光學分析設計後,透鏡將雷射光源投射於數公尺至數公里距離。光型發散角度可由20度集中至大角度120度發散光。大幅提升雷射光源於安防系統上運用及提升效能。
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/53.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/54.png)
產品-定焦照相模組
PLCC Package Sensor Cap
Barrel
- Size:M3 ~ M7
- 同軸度:0.002 (mm)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/55.png)
Holder
- 規格:4.5 x 4.5 ~ 12 x 12 (mm)
- Pitch:0.18mm (min)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/56.png)
Dam
- 尺寸:6 x 6 , 8 x 8 , 10 x 10 (mm)
- 可過迴焊爐。(高溫製程)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/57.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/58.png)
使用於CMOS影像照相模組,泛用於電腦前置鏡頭及平板定焦鏡頭使用。
產品-自動對焦照相模組
VCM Holder
- 尺寸:6.5 x 6.5 , 8.5 x 8.5 , 10 x 10 (mm)
- 可過迴焊爐。(高溫製程)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/62-1.png)
連板設計
- 尺寸:50 x 50 x 0.3 (mm)
- 可過迴焊爐。(高溫製程)
- 大幅度提升生產效率。
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/63-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/68.png)
使用於CMOS影像照相模組,泛用於手機使用,自動對焦功能搭配VCM(音圈馬達)。
非線性超精密模仁加工及模具製作
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/71-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/72-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/74-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/73-1.png)
XY Polynomial Curve
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/74-5.png)
3D自由曲面加工實例
- 材質 : DC53 60HRC
- 表面粗糙度 Ra < 0.02 um
- 尺寸精度 < 0.1um
產品-閃光燈罩
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/78-1024x400.png)
運用於手機或平板電腦上的照相閃光燈模組鏡片,其功能將光線均勻的擴散於預拍攝物體上,並於光學設計變更其光型。
表面粗度可達Ra 0.01um。
產品-Tiinlab 耳機飾蓋
產品導入知名品牌 Tiinlab 耳機外觀產品使用。
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/91-1-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/92-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/93-1.png)
產品-TV & Car LENS光學透鏡
提供完整光學設計及分析服務,提升光學透鏡於直下式背光模組之光均勻度及角度,降低LED使用數量,大幅彰顯光學設計之效益。
TV Lens
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/94.png)
TV Lens-OD28
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/95.png)
Lens-OD25
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/96-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a1-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a2.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a3.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a4.png)
提供專業的光學模擬分析精密模具開發,實踐產品使用於高規格LED車用頭燈。
指紋辨識 Prism
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a5.png)
太陽能應用
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a6.png)
安防監控光學外罩
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a7.png)
安防監控光學外罩
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a8.png)
產品-高精度醫療檢驗產品
醫療檢驗封裝產品,訴求產品精度規格0.01mm,平整度及腔體氣流動向管控。
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/b1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/b2.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/b3.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/b4.png)
產品-雷射光學鏡片
雷射光學鏡片廣泛應用於面射型雷射監視器、行車記錄器、夜間車用長距紅外線照明雷射滑鼠、體感測器、工業雷射、醫療雷射、實驗室雷射、雷射全像、氣體雷射、光纖雷射。
Laser Lens 45度°
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/c1.png)
Laser Lens 30°
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/c2.png)
Laser Lens 95°
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/c3.png)
Laser Lens 60°
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/c4.png)
照相模組
影像模組埋入射出能力:
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/e1.png)
(CMOS Sensor Insert Molding)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/e3.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/0001.jpg)
4.5 x 4.5 x 2.5 mm
車載照明模組
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a01.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a02.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a03.jpg)
紅外光 Cover Lens
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a04.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a05.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a06.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a07.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a08.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a09.jpg)
雷射測距對焦方案
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a10.png)
小而巧
•市面上最小的雷射測距模塊
•精準的距離量測
量測範圍
第一代產品最遠可達40cm
第二代產品最遠可達200cm
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a11.png)
便利性
整合優質光學透鏡,穿透率,霧度及表面平整度等各項指標領先同業
使用I²C接口控制與數據存取
連接4pin即可啟動,校正完成,直接給讀值
紅外線3D感測
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a13.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a14.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a15.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a16.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a17.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a18.jpg)
