产品运用-安防系统
光学分析设计后,透镜将雷射光源投射于数公尺至数公里距离。光型发散角度可由20度集中至大角度120度发散光。大幅提升雷射光源于安防系统上运用及提升效能。
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/53.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/54.png)
产品-定焦照相模组
PLCC Package Sensor Cap
Barrel
- Size:M3 ~ M7
- 同轴度:0.002 (mm)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/55.png)
Holder
- 规格:4.5 x 4.5 ~ 12 x 12 (mm)
- Pitch:0.18mm (min)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/56.png)
Dam
- 尺寸:6 x 6 , 8 x 8 , 10 x 10 (mm)
- 可过回焊炉。 (高温制程)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/57.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/58.png)
使用于CMOS影像照相模组,泛用于电脑前置镜头及平板定焦镜头使用。
产品-自动对焦照相模组
VCM Holder
- 尺寸:6.5 x 6.5 , 8.5 x 8.5 , 10 x 10 (mm)
- 可过回焊炉。 (高温制程)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/62-1.png)
连板设计
- 尺寸:50 x 50 x 0.3 (mm)
- 可过回焊炉。 (高温制程)
- 大幅度提升生产效率。
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/63-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/68.png)
使用于CMOS影像照相模组,泛用于手机使用,自动对焦功能搭配VCM(音圈马达)。
非线性超精密模仁加工及模具制作
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/71-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/72-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/74-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/73-1.png)
XY Polynomial Curve
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/74-5.png)
3D自由曲面加工实例
- 材質 : DC53 60HRC
- 表面粗糙度 Ra < 0.02 um
- 尺寸精度 < 0.1um
产品-闪光灯罩
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/78-1024x400.png)
运用于手机或平板电脑上的照相闪光灯模组镜片,其功能将光线均匀的扩散于预拍摄物体上,并于光学设计变更其光型。
表面粗度可达Ra 0.01um。
产品-Tiinlab 耳机饰盖
产品导入知名品牌 Tiinlab 耳机外观产品使用。
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/91-1-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/92-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/93-1.png)
产品-TV & Car LENS光学透镜
提供完整光学设计及分析服务,提升光学透镜于直下式背光模组之光均匀度及角度,降低LED使用数量,大幅彰显光学设计之效益。
TV Lens
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/94.png)
TV Lens-OD28
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/95.png)
Lens-OD25
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/96-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a1-1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a2.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a3.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a4.png)
提供专业的光学模拟分析精密模具开发,实践产品使用于高规格LED车用头灯。
指纹辨识 Prism
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a5.png)
太阳能应用
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a6.png)
安防监控光学外罩
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a7.png)
安防监控光学外罩
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a8.png)
产品-高精度医疗检验产品
医疗检验封装产品,诉求产品精度规格0.01mm,平整度及腔体气流动向管控。
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/b1.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/b2.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/b3.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/b4.png)
产品-雷射光学镜片
雷射光学镜片广泛应用于面射型雷射监视器、行车记录器、夜间车用长距红外线照明雷射滑鼠、体感测器、工业雷射、医疗雷射、实验室雷射、雷射全像、气体雷射、光纤雷射。
Laser Lens 45°
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/c1.png)
Laser Lens 30°
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/c2.png)
Laser Lens 95°
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/c3.png)
Laser Lens 60°
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/c4.png)
照相模组
影像模组埋入射出能力:
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/e1.png)
(CMOS Sensor Insert Molding)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/e3.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/0001.jpg)
4.5 x 4.5 x 2.5 mm
车载照明模组
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a01.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a02.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a03.jpg)
紅外光 Cover Lens
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a04.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a05.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a06.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a07.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a08.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a09.jpg)
雷射测距对焦方案
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a10.png)
小而巧
•市面上最小的雷射测距模块
•精准的距离量测
量测范围
第一代产品最远可达40cm
第二代产品最远可达200cm
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a11.png)
便利性
整合优质光学透镜,穿透率,雾度及表面平整度等各项指标领先同业
使用I²C接口控制与数据存取
连接4pin即可启动,校正完成,直接给读值
红外线3D感测
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a13.png)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a14.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a15.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a16.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a17.jpg)
![](https://www.hornix.com.tw/wp-content/uploads/2019/01/a18.jpg)
